Combined Cyclic Tester Specifications · Testing Methods :SOAK, ACSS, DRY AIR, HUMI · Inside Dimension (WxHxD) : 960x860x510mm · Outside Dimension ( WxHxD): 1500x1700x1000mm · Test Temperature Range : -20oC ~+80oC · Salt Spray Temperature range : :RT~+5oC~50oC · Salt Soak Temperature : RT~+10oC~60oC · Dry Air Temperature : RT~+10oC~70oC · Humidity Range…
Details
Programmable Infra-Red Chamber Specifications · Inside Dimension (WxHxD) :2000x800x1500mm · Outside Dimension (WxHxD) :2500x2300x1700mm · Temperature range : Ambient ~+250oC with Heater · Ambient ~ +150oC with IR source · Temperature uniformity :±0.5oC · Temperature indicator :±0.3oC · Heat up time : Ambient ~ +250oCwithin 30min with · Heater only · Ambient ~+150oC within…
Details
Dust Tester Specifications Inside Dimension (WxHxD) :900x900x900mm Outside Dimension (WxHxD) :1550x1800x1300mm Temperature range :20oC±15oC Temperature resolution :±0.1oC Humidity Range : 45%~85%RH Dust Concentration: *F1:6000mg/m3 F2: 3000 mg/m3 F3: 100 mg/m3 * C1: 5000mg/ m3/5m/s C2:100 mg/ m3/5m/s Test Cycling : 0 ~999s or0~ 99Hrs Power Consumption : 220V,5KW Weight : 320kg Safety devices :…
Details
Fade Meter Specifications · Lighting Source : U.V.R Carbon · Inside Dimension (WxHxD) : 700x900x700mm · Outside Dimension (WxHxD) : 1150x1800x900mm · Testing Time : 20Hrs · Testing Voltage : 120V – 145V · Testing Current : 15A-17A · Specimen Drum : 508mm Diameter · Drum Rotation Speed : 3-4 RPM · Temperature range…
Details
Geer’s Aging Oven Specifications · Inside Dimension (WxHxD) : 450x500x450mm (A) 600x600x600mm (B) · Temperature range : RT ~ 300oC · Temperature uniformity : ±0.5oC · Temperature resolution : ±0.1oC · Temperature indicator : ±0.3oC · Rotation Speed : 8 ~ 10 RPM · Air Refresh : 1 – 200 times /Hr (…
Details
