QC-H55 Electromechanical Universal Testing Machine (500kN)

Force Capacity: 10N,20N,50N,100N,200N,500N,1kN,5kN,10kN, 20kN,100kN, 200kN, 300kN, 500kN

QC-H55 Series electromechanical tabletop single column test machines serve high elongation applications such as rubber, plastic film, elastomer, glues, adhesive and medical applications. Configurations are available from 10N to 500 kN  force ratings with test speeds up to 1000 mm/min. Controllers ranging from simple to use standalone controllers to fully flexible PC based controllers.

Features & Benefits

  • Single column vertical load frame with either stand-alone or computerized controllers.
  • Wide range of load cells to serve a variety of applications.
  • Load cell accurate from 100 to 1 % of rating. Load accuracy +/- 0.5% of indicated load within load cell rated force range.
  • 1000 samples per second data acquisition rate on load, position, and strain channels.
  • Three choices of Controllers: TouchPad Standalone, TouchPad Computerized and Fully Computerized Controller
  • Wide range of compatible optional accessories including tensile grips, compression and bend fixtures, environmental chambers, extensometers, etc.
  • 12 month warranty and customer support services.

Specifications

Force
500 kN
Speed
300 mm/min
Column Clearance
550 mm
Travel
1000 mm

Controller

YY-K5A controllers feature constant rate of extension (constant speed) and constant load control for proof tests. YY-K5A controllers capture and display test data and are capable of stand alone operation without a computer. Computerized software based operation is available with an optional software program running on a PC. View the Documents tab for more information.
